Carbonaut 25x25x0.2mm

The Carbonaut high-tech carbon pads are excellent as an alternative for thermal conductive pastes. They have a very elastic and adaptable surface with very high thermal conductivity.
The high-tech carbon thermal pads of the Thermal Grizzly Carbonaut series are an excellent alternative to mid-range thermal pastes. They have a highly elastic and adaptable surface, allowing even the smallest component differences to be effectively compensated. Carbonaut provides high thermal conductivity with extreme long-term stability.
Properties:
High thermal conductivity
Consistently high performance
Does not dry out
Flexible and easy to apply
Material Properties and Thermal Conductivity
The Thermal Grizzly Carbonaut pad is a thermal pad made from carbon fiber. Its specially developed polymer gives the thermal pad its flexibility and “Soft Gap Filler” properties. The carbon fiber structure ensures outstanding thermal conductivity. Additionally, the Thermal Grizzly Carbonaut pad offers high thermal conductivity, which it can already achieve with very low contact pressure. The Thermal Grizzly Carbonaut pad maintains consistent thermal transfer performance.
Pre-cut Sizes for CPUs and GPUs:
25 × 25 mm: Nvidia GPUs – e.g. RTX 2080
31 × 25 mm: Nvidia GPUs – e.g. RTX 2080 Ti
32 × 32 mm: Intel Desktop CPUs (115x) – e.g. 6700K, 7700K, 9900K
38 × 38 mm: Intel 20xx HEDT CPUs and AMD Desktop CPUs – e.g. 7900X, 7980XE, 2700X, 1800X, 6950X
51 × 68 mm: AMD Threadripper CPUs – e.g. 1950X, 1920X, 2990WX
Note:
Carbonaut is electrically conductive!
